ELCERAM Oxide 1:8 G1 Competition Offroad Brushless ESC
The Oxide 1/8 from ELCERAM brings groundbreaking innovations in real-time monitoring of battery current and discharge as well as intelligent algorithms to protect the regulator. Using advanced cooling technology based on an aluminum oxide ceramic cooler, Oxide 1/8 offers excellent thermal conductivity and can be used with powerful motors up to 2300kV. It offers revolutionary real-time monitoring of battery current and discharge as well as innovative intelligent algorithms to protect the ESC in the event of a motor failure or mechanical problem. With reverse polarity protection and improved water and dust resistance, the controller stands out with its matte TFT LCD color display, eliminating the need for another interface.
Programmable parameters and functions: - Revolutionary easy Rx calibration. - Real-time monitoring: battery voltage, ESC and motor temperatures, motor diagnostics and more. - Revolutionary monitoring of battery current and discharge. - Pre-diagnosis before the race: Motor temperature, sensor cable, defective motor, battery, BEC voltage and more. - Easy programming: throttle, brake, boost and turbo timing, Hall angle and many more functions. - Race data logging, temperature and other curves, histograms and more. - Adjustable maintenance reminder for easy checking. - No programming interface required.
Key features: - TFT LCD color display with matte finish - The LCD color display with a resolution of 160 x 80 pixels allows you to set all parameters and check all data directly on your ESC without the need for a programming card or mobile application. Everything you need is inside your ESC. It's really easy to use - 3 buttons allow you to quickly set everything you need and a single glance is enough to check all the parameters necessary for the race. Simple. Fast. Precise. - Easy to check and adjust - The display gives you an overview of all important data and events - before the race, during the race and after the race. You can quickly change your settings and get instant feedback without the delay of connecting an external control interface. - High-performance electronics for professional RC racing. - Advanced cooling technology for 1/8 scale RC cars - Advanced cooling technology - The advanced cooling technology used by OXIDE is based on an aluminum oxide heat sink specially designed for OXIDE, giving the ESC excellent thermal conductivity and long-term resistance to high temperatures and loads. - MOSFET transistors are cooled directly without any additional thermal resistance layer! During production, ELCERAM used very thick layers of special materials such as silver and copper for very low internal resistance and the latest technologies inspired by advanced power supply systems developed and manufactured by ELCERAM. - Reverse polarity protection. - Intelligent algorithms to protect the ESC. - Dimensions - Despite the many great new features, the OXIDE 1/8 is really compact. Its dimensions are suitable for all types of 1/8 off-road RC cars. In addition, 70% of the weight is on the bottom of the ESC, giving your car even more stability! - Easy installation - The installation of OXIDE 1/8 is quick and easy - with double-sided tape or two M2.5 screws included in the package. In addition, the cover of the ESC with display and buttons can be easily replaced in the event of an accident. The cover can be rotated 180° if required.
Technical data: - Scale: 1/8 offroad - Type: Brushless sensor - Waterproof: Yes - Reverse polarity protection: Yes - Relevant parameters: Continuous current/peak current: 200A / 1500A - Input voltage: 2S - 4S LiPo - BEC output voltage adjustable: 6.0 - 8.4V - BEC current continuous/peak: 6A/15A - Size: 50x40x28 mm - Weight: 112 g without cable / cable AWG11 - 200 mm. - BEC cable length: 180 mm, gray stripe is negative pole
Applications: - Applications: Brushless sensor DC motors up to 2300 kV - Vehicles: 1/8 buggy, truggy and monster trucks - Support for zero timing (blinky mode). - External capacitors required (included)
